| Wire sizes | Up to 300 mm2?(600 MCM)*? |
| Outer wire diameter | Up to 35 mm (1.4”) * |
| Minimum wire length? | Standard mode: 152 mm (6’’)?; short mode |
| Strip lengths | Strip lengths pull values 1,0 – 1000 mm |
| Full strip removal length | |
| left side 168 mm, right side 518 mm | |
| Electrical requirement | 220 VAC, 1 phase, 50/60 Hz |
| Air requirement | 5 CFM (Cubic feet/min.) 5 – 6 bar (80 psi) |
| Dimensions | Length 1790 mm (70,5 inches), ? machine body 2940 mm (115,75 inches) with operator station and single ? straightener width 605 mm (24 inches), height 1453 mm (57 inches) |
| Weight | 820 kg (1808 lbs.) – machine weight |
| 1090 kg (2400 lbs.) – packed weight | |
| *?wire ? dependent, may require purchase of one or more options shown. | |
